Stainless Steel Control Cabinet 800x800x300 mm (HBT) V2A Enclosure, Single-Door, IP66
Fully enclosed stainless steel enclosure, 800x800x300, with a standard door and two independent locking mechanisms.
This enclosure series is well-suited for industries such as the food, beverage, and pharmaceutical sectors
as well as (depending on requirements) for harsh environments with elevated material requirements.
For coastal use and seawater-resistant applications, the enclosures are also available in V4A 316L stainless steel upon request!
Feature: IP 66 TYPE 4X, 12 IK 10
This enclosure series is well-suited for industries such as the food, beverage, and pharmaceutical sectors
as well as (depending on requirements) for harsh environments with elevated material requirements.
For coastal use and seawater-resistant applications, the enclosures are also available in V4A 316L stainless steel upon request!
Feature: IP 66 TYPE 4X, 12 IK 10
| Features | |
|---|---|
| Note | With mounting plate |
| Height | 800 mm |
| Width | 800 mm |
| Depth | 300 mm |
| Mounting Plate Height | 770 mm |
| Mounting Plate Width | 750 mm |
| Max. usable depth of the housing |
282 mm |
| No. of Locks | 2 |
| Weight (kg) | 37.00 |
Material: Pre-polished AISI 304L stainless steel
Material thickness: 1.5 mm. Door for AISI 304L: 1.5 mm / 2 mm for cabinets with a height or width of 600 mm or more
Mounting plate: 2 mm galvanized sheet steel.
3-mm double-bit lock made of Zamak with a 90° range of motion and a vibration-damping mechanism.
Two locks for cabinets with a height of 600 mm to 800 mm.
Three-point twist-bar lock or three locks for cabinets 1,000 mm high and taller.
Stainless steel locks and other versions are available as accessories.
Cabinet body: Folded and seam-welded.
For easy installation, all rear corners of the cabinet are laser-marked,
indicating where to drill the holes and attach the wall brackets.
Door: formed from a single piece. Surface-mounted with a 130-degree opening.
Concealed hinges made of AISI 304 stainless steel with captive pins.
Can be mounted to allow opening to the left or right.
Sealing is provided by an injection-molded polyurethane gasket.
Internal M6 welded studs for mounting optional door profiles.
Cable entry: No flange openings as standard to optimize sealing and cleanliness.
Certifications: CSA, DNV-GL, GOST, Kema Keur - DEKRA, Lloyd's Register, Russian Maritime Register of Shipping, cULus_UL Listed, IEC 61439 Declaration of Compliance
Protection rating: Equivalent to IP66 | TYPE 4X, 12 | IK 10.
Surface: Pre-polished 400-series stainless steel.
Scope of delivery: Cabinet with door, mounting plate, double-bit plastic key (3 mm), and mounting hardware.
Metal key, for cabinets 1,000 mm high and taller.
